| Optical Magnification |
0.3X~0.4X |
| Sensor |
Ф90 |
| Working Distance |
0.259x、WD= 480.4mm、OI = 701.75mm |
| 0.27x、WD= 464.1mm、OI = 686.69mm |
| 0.3x、WD= 424.4mm、OI = 650.6mm |
| 0.35x、WD=372.9 mm、OI = 604.4mm |
| 0.4x、WD= 334mm、OI = 571.5mm |
| 0.448X、WD=306.5mm、OI=547.8mm |
| Effective F/# |
F4.2~F11 |
| Resolution |
<5μm |
| DOF |
±0.05mm @60lp MTF > 0.3 |
| Distortion |
<0.1% |
| RI |
>90% @ Ф66 |
| >85% @ Ф86 |
| MTF @40 lp/mm |
>70 |
| Wavelength |
450nm – 650nm |
